I made a bracket that looked like the ones that different companies sell. I have seen pictures of the kx 65 master cylinder mounted with this bracket but i sure as heck couldn't get it to line up. It may have just been the TBR brake pedal i am using. Either way it wouldn't line up with out hitting my cases. I made a bracket to fix that tonight. It allowed me to rotate the master cylinder around to line up with the pedal.

Here is my set up now. It seems to work great





I also made a bracket to hold my rear caliper. The pictures i have of it are kind of lame though.

Not my current swing arm



[Cokeham]

Sweet!



[txmxer]

Nice, im about to do the same thing on my 110, just need to get a hold of a bracket...



[blackedoutv6]

Looks nice! I am wanting to do the same thing soon, how did you make those brackets? Im a waterjet operator so cutting them out is no big deal but I have no idea on the dimensions...



[goinsriding]

I measured the holes in the master cylinder. Pretty easy



[Jarret53]

Very nice work, im sure you could sell a few of those brackets pretty easily



[blackedoutv6]

I'm more curious about the caliper bracket, I've never seen one not mounted on a bike...



[TPalmKlx4]

Awesome man. Let me know how it performs. I want to do that to my 110



[goinsriding]

I'm more curious about the caliper bracket, I've never seen one not mounted on a bike...

I'll have to take it off of the bike to take better pictures of it.

Awesome man. Let me know how it performs. I want to do that to my 110

It works perfect. Very solid. The stock kx65 brake line would even work with it but i didn't know that at first so i bought a longer one and now it may be too long.



[txmxer]

Yeah if you make more I would probably buy one off ya



[elixur]

What rear wheel are you running? It looks like a china one which is no big deal at all but I wonder how close it is to a kx65 wheel. The china wheel may be a better option considering kx hubs only fit a 38 tooth rear sprocket before you have to start shaving and then the sprocket will have to be custom made.



[goinsriding]

it is a china wheel. So i made the brake bracket fit that one. It wouldn't be hard to change my program to make my bracket fit a kx65 rear wheel.



[elixur]

I wonder how much of a difference there is spacing wise. But like I said the china wheel I think would probably be a better setup for sprockets.
Either way I doubt you'll have a hard time selling them if you decide too



[goinsriding]

I'm more curious about the caliper bracket, I've never seen one not mounted on a bike...

Here are a few pictures of the caliper bracket



[fiftynutsrider]

If you make another bracket ill take one



[Cokeham]

If you make another bracket ill take one

Me to!



[motorheadparts1]

I'm thinking u got done serious skill and a good way to make some bones!



[goinsriding]

I would make a few more but there are a lot of variables with this stuff. I don't want someone getting ozone and then it not fit their bike because they are using something different than what I used.

The chp brake pedal lined up differently than my two bros did. Also what if someone used a different wheel and swing arm than I did. I don't want someone ripping me apart because it doesn't fit exactly like mine did. If that sounds crazy then let me know.



[fiftynutsrider]

Im using a kx65 rear wheel and brakes with a metal tek plus 4 swinger



[goinsriding]

really the only thing that would change would be the thick part of the bracket. That would be only if the wheels hubs are different which they probably are.
