thats sweet!



thats sweet you gunna run it next year at the pit bike races at the regionals at wsp



thats sweet you gunna run it next year at the pit bike races at the regionals at wsp

Yeah I ran it this year too. I was in the lead...Until my back tire fell off:x



is that a kx 65 swingarm ? how do you like it?



is that a kx 65 swingarm ? how do you like it?

I like it alot. Im gonna rebuild it though, slightly differant..I also need a newer shock (with clickers) and a higher rate spring.. The early model shocks have no adjustment to em.



wow those are long



Yeah I ran it this year too. I was in the lead...Until my back tire fell off:x

that sucks ya i remember seeing the bike. wanted to race it soo bad but my dad didnt want me getting screwed up for regionals so



Man it is kinda tall. Maybe get the vinco internals? At least you have some good brakes.



Take them apart and make 2 inch pvc spacers the same od as the top out springs and install them under the top out springs. Then shorten the fork springs 1.5 inches. Those measurements may not be exact but you will get the idea when you take them apart. Just play with the spacers and the springs until you get the right combo to get the 2 inch drop. Or slide them through the clamps a bit to drop it and keep the travel.. Also you can drop the forks through the clamps to fine tune the lowering of the forks to get it just right.



Take them apart and make 2 inch pvc spacers the same od as the top out springs and install them under the top out springs. Then shorten the fork springs 1.5 inches. Those measurements may not be exact but you will get the idea when you take them apart. Just play with the spacers and the springs until you get the right combo to get the 2 inch drop. Or slide them through the clamps a bit to drop it and keep the travel.. Also you can drop the forks through the clamps to fine tune the lowering of the forks to get it just right.

Forks are dropped all the way in the clamps already. Im just gonna take it to the guy who deos my suspension... Nice to have sponsors:grin:



Forks are dropped all the way in the clamps already. Im just gonna take it to the guy who deos my suspension... Nice to have sponsors:grin:

How much would it cost to have them shortened 2" ? I have access to a pair of these forks, What did you have to do to get these on the 110 ???



How much would it cost to have them shortened 2" ? I have access to a pair of these forks, What did you have to do to get these on the 110 ???

You need the clamps, and 2 sets of tapered bearings for the klx110. You use both upper bearings/ races. you might need to take some sand paper and sand the stem just a lil down bottom but the bearing will go on. Thats it... slide it together and ride away...



As for shortening them...im not sure how much it costs...



Also you need an 85 hub, brakes and 65 wheel.



klx fender will fit on, so will the number plate with a lil modification, or you can use an 85 number plate...an 85 fender would look goofy...



Thanks for the info.



The clamps being kx85 triple clamps ? Use both klx110 bearings on the top of stem ? or 2 top and 2 bottom ?



Please do NOT use PVC to space the damper 2"!!! Do it properly, or have your suspension guy contact Velocity Suspension and they will walk him through the process. PM me for their contact info so I don't get yelled at for advertising for them.



Thanks for the info.



The clamps being kx85 triple clamps ? Use both klx110 bearings on the top of stem ? or 2 top and 2 bottom ?

Kx 85 clamps, yes. I went aftermarket top clamp. You use 1 top bearing from each kit. The bearing diameter is the same on the kx85 (top and bottom) and the klx is not. Thats whys you need two top bearings.



Please do NOT use PVC to space the damper 2"!!! Do it properly, or have your suspension guy contact Velocity Suspension and they will walk him through the process. PM me for their contact info so I don't get yelled at for advertising for them.

Thanks for the info, ill be in touch when im getting it done.



sweet lots of travel



Looks nice.



So you lace up the 85 hub to a 65 rim so you get the 65 wheel size but 85 brakes. Did you use 65 spokes to do that also?



Does not look bad at all but I would like to see a picture of the bike on the ground. It seems level when on the stand.



I got the sano mx swingarm kit so it should not be too bad.



I think I may go with this in the spring.



Forgot to say a kid down the road from me put a 85 swinger on his bike but he only has 60 forks on it. If it had 85 forks like yours it would sit perfect but right now it looks goofy as hell.



I Have A Set Of Showa Cr85 Forks In The Classified Section $200 +shipping.



Looks nice.



So you lace up the 85 hub to a 65 rim so you get the 65 wheel size but 85 brakes. Did you use 65 spokes to do that also?



Does not look bad at all but I would like to see a picture of the bike on the ground. It seems level when on the stand.



I got the sano mx swingarm kit so it should not be too bad.



I think I may go with this in the spring.

65 rim and spokes... I will need to get the fork shortened but when i do it'll sit perfect with any swinger (bbr-sano-etc) This is from comparisons of my bike next to others.



Yup, 85 brakes:grin:



Its not that cheap, but its top of the line for sure. Considering you could buy a cheap 85 (the whole bike) for what you can buy zokes for you could part the rest and come out alot farther ahead.



I bought alot of the part separate so it cost more, then again most of my stuff is new or after market (black fork sliders, excel rim, triple clamps, etc...)



Cr forks would work better cause you can slide then farther up in the clamps (the forks arent tapered like the kx's) but im not sure if they'd fit in the clamps or not...



Let me know where you get your forks shortend and how much it was.

MX-TECH suspension is only like a half a hour from me. I wonder if they can do it for me? You say about two inches right. I may call them and see how much and if they can.



Which two bearings do I use from both sets of taper 110 bearings and do I put both of them on the bottom of the stem before I slide the lower clamp in the head tube or one on top and bottom.



One more question would I need a aftermarket top clamp or would the stock top clamp work fine? I just did not know if the forks with a stock top clamp would run into problems when I try to level the bike by sliding the forks up in the clamps cause of the bars.



Thanks



Does anyone know if that wheel setup will work for a 110 with kx65 forks ???

I mean kx 85 hub with 65 rim and spokes ??? Please let me know ....



I have kx65 forks and I can get a 85 wheel for cheap since I can not find a deal on a 65 wheel



Does anyone know if that wheel setup will work for a 110 with kx65 forks ???

I mean kx 85 hub with 65 rim and spokes ??? Please let me know ....



I have kx65 forks and I can get a 85 wheel for cheap since I can not find a deal on a 65 wheel

'



I willing to be it would work but honestly dont know...



Let me know where you get your forks shortend and how much it was.

MX-TECH suspension is only like a half a hour from me. I wonder if they can do it for me? You say about two inches right. I may call them and see how much and if they can.



Which two bearings do I use from both sets of taper 110 bearings and do I put both of them on the bottom of the stem before I slide the lower clamp in the head tube or one on top and bottom.



One more question would I need a aftermarket top clamp or would the stock top clamp work fine? I just did not know if the forks with a stock top clamp would run into problems when I try to level the bike by sliding the forks up in the clamps cause of the bars.



Thanks

Stock clamp will work fine...



2 sets of tapered bearings. In each set there are 2 bearings, 1 big, 1 small. You use both small bearings and assemble it like any other triple clamp assembly.
